2005 GMC Sierra 3500 Remote PN: 21997127, 15186203

Extended warranty is available on the checkout page.

Most vehicles that use this remote are onboard programmable and the remote includes programming instructions and free tech support if needed.  (Vehicles that are not onboard programmable are Equinox, Torrent, and Vue.  All others are onboard programmable.)

Remote For GMC Cadillac Chevrolet Hummer Pontiac Saturn:

FCC ID: LHJ011

GM Part Numbers: 21997127

Condition: Brand New Aftermarket (No Logo)

Brand: Avicero

GM's current part number is 21997127.  Your old remote has one of these discontinued numbers: 15186200, 15186201, 15132197, 15132198, 10377295, 22730827, and 15186203.  The FCC ID is LHJ011. GM has remade this remote many times. They originally had memory #1 and #2 remotes. The purpose was for vehicles with seat memory. In reality it was ridiculous because the order that you program them determines which is #1 and #2. The numbers on the back were just for reference. In 2006 GM decided to discontinue using #1 and #2 and they started making un-numbered remotes. GM's current part number for this remote is 21997127. If you go to a GM dealer parts department you will get the new number remote no matter what remote you have now. All the remotes with the part numbers listed above are identical inside and in function so we mix them together.

Programming Procedure:

IMPORTANT: Before entering programming mode, have in possession all of the transmitters you will be using on the vehicle. Once you program the transmitter, all previous codes will be erased from the memory. The other transmitters will not be functional until you program the transmitters again.

1. Close all vehicle doors, windows closed, wait for dome light to go off.
2. Insert the key into the ignition.
3. Hold down the power UNLOCK button on the driver?? door panel-continue to hold down until instructed to release in step 9.
4. Perform steps 5 through 8 in fairly rapid succession.
5. Turn the ignition switch to the ON position (as far as you can go without starting the engine).
6. Turn the ignition switch to the OFF position.
7. Turn the ignition switch to the ON position.
8. Turn the ignition switch to the OFF position.
9. Release the power unlock button on the door panel. The vehicle will lock and unlock the doors automatically.
10.Hold down the LOCK and UNLOCK buttons on the transmitter simultaneously until the door locks and unlocks. This step may take up to 30 seconds.
11.Repeat step 10 for each additional transmitter (including any existing transmitters).
12.Turn the ignition switch to the ON position in order to exit the transmitter programming mode.

The following vehicles can use this remote when equipped with the factory keyless entry system:

Cadillac: Escalade (2003-2006),  Escalade ESV (2003-2006), Escalade EXT (2003-2006);

Chevrolet: Avalanche 1500 (2003-2006), Avalanche 2500 (2003-2006), Equinox (2005-2006), Silverado 1500 (2003-2006), Silverado 1500 (2007),  Silverado 1500 Classic (2007),  Silverado 1500 HD (2003-2006),  Silverado 1500 HD Classic (2007),  Silverado 2500 (2003-2006),  Silverado 2500 (2007), Silverado 2500 HD (2003-2006), Silverado 2500 HD (2007),  Silverado 2500 HD Classic (2007),  Silverado 3500 (2003-2006),  Silverado 3500(2007),  Silverado 3500 Classic (2007), Silverado 3500 HD (2007),  Suburban (2003-2006),  Suburban 1500 (2003-2006),  Suburban 2500 (2003-2006),  Tahoe (2003-2006);

GMC: Sierra Denali (2003-2006), Sierra 1500 (2003-2006), Sierra 1500 Classic (2007),  Sierra 1500 HD (2003-2006),  Sierra 1500 HD Classic (2007), Sierra 2500 (2003-2004), Sierra 2500 HD (2003-2006),  Sierra 2500 HD Classic (2007), Sierra 3500 (2003-2006), Sierra 3500 Classic (2007), Yukon (2003-2006),  Yukon Denali (2003-2006), Yukon Denali XL (2003-2006), Yukon XL 1500 (2003-2006), Yukon XL 2500 (2003-2006);

Hummer: H2 (2003-2007);

Pontiac: Torrent (2006);

Saturn: Vue (2004-2007);
