Important Note:
Please note that aftermarket remote controls are not universally compatible. They are designed for specific aftermarket systems.
If you're here without checking your existing remote's FCC ID/Part Number or your system model under the dash, please contact us at:
Description
Audiovox Part Numbers: APS2K4SFLCF, APS2K4SFLCF110P, APS2K4SCF50P, APS2K4SBCF50, APS2K4SBCF52P, APS2K4SBCF52, APS2K4SFLCF112P. Basically any part number that starts with APS2K4S... is compatible. The FCC ID on this remote can be ELVATOC or ELVATOD or ELVATOH.
The circuit board ID is either ADTH, ATDH, and ATFF.) This remote's Frequency is 434 MHz. The LED color is Red. This remote has 4 buttons on front (some have one on the side.) This remote works on these Prestige Systems: APS55C, APS55LRA, APS55TW, APS55TWT, APS686T, APS686TC, APS410A, APS510A, APS510B, APS511C, APS590, APS596, APS596A, APS610A, APS610C, APS687N, APS786, APS787N, APS997N. Battery and tech support are included with the purchase.
Programming Procedure:
1. Enter the vehicle and turn the ignition key to the "on" position.
2. Press valet button 3 times.
3. If installed, the dash LED will flash one time, and the siren will "chirp" one time, indicating the
system is ready to accept programming for channel 1.
4. Press button #1 on the keychain transmitter for 1-3 seconds until the siren emits a long "chirp" to
confirm that programming of channel I was successful. If your remote has one button, then skip
to last step.
5. Press valet button 1 time.
6. If installed, the dash LED will flash twice, and the siren will "chirp" twice, indicating the system is
ready to accept programming for channel 2.
7. Press button #2 on the keychain transmitter for 1-3 seconds until the siren emits a long "chirp" to
confirm that programming of channel I was successful. If your remote has two buttons, then skip
to last step.
8. Press valet button 1 time.
9. If installed, the dash LED will flash thrice, and the siren will "chirp" thrice, indicating the system is
ready to accept programming for channel 3.
10. Press button #3 on the keychain transmitter for 1-3 seconds until the siren emits a long "chirp" to
confirm that programming of channel I was successful. If your remote has three buttons, then
skip to last step.
11. If installed, the dash LED will flash four times, and the siren will "chirp" four times, indicating the
system is ready to accept programming for channel 4.
12. Press button #4 on the keychain transmitter for 1-3 seconds until the siren emits a long "chirp" to
confirm that programming of channel I was successful. If your remote has three buttons, then
skip to last step.
13. If the remote has 5 or more buttons, then continue the sequence described above programming
the remaining buttons to the remaining channels.
14. To exit program mode, either turn the ignition key to the off position, or move the valet switch on
then off one additional time. This is indicated by a long "chirp" from the siren.
