Specifications
Part Numbers: 35111-STX-325, 35111-STX-315, and 35111-STX-305
FCC ID: N5F0602AIA
Buttons: Lock, Unlock, and Panic
Frequency: 314 MHz
Remote Programming:
Transponder Programming:
Chip ID: PHILIPS ID 46
Led:
Description
Extended warranty is available on the checkout page.
FCC ID : N5F0602AIA
Part Numbers : 35111-STX-325, 35111-STX-315
Brand : Avicero
Condition : New
Remote Programming Procedure :
IMPORTANT : Entering the programming mode cancels all learned remote codes, so no previously programmed remotes will work. You must program all remotes, including existing ones now. Separate your ignition key from remotes on keychain.
1. Start with your key in your right hand and any remote in your left hand. Keep all additional remotes easily accessible to your left hand. Insert the key into the ignition.
2. Perform these steps within 5 seconds.
a. Turn the ignition to the ON position (where the instrument panel lights are turned on without starting the engine.)
b. Press the UNLOCK button on the remote and release.
c. Turn the ignition back to LOCK (the position where the key is inserted) and leave the key in the ignition.
d. Turn the ignition to the ON position (where the instrument panel lights are turned on without starting the engine.)
e. Press the UNLOCK button on the remote and release.
f. Turn the ignition back to LOCK (the position where the key is inserted) and leave the key in the ignition.
g. Turn the ignition to the ON position (where the instrument panel lights are turned on without starting the engine.)
h. Press the UNLOCK button on the remote and release.
i. Turn the ignition back to LOCK (the position where the key is inserted) and leave the key in the ignition.
3. Within 5 seconds turn the ignition to ON.
4. Press the UNLOCK button on the same remote and release. The power door locks will cycle to confirm the system is in programming mode.
5. Within 10 seconds press the UNLOCK button on the same remote again and release. The door locks will cycle to confirm that the system accepted this remote.
6. Repeat step 5 for second or third remotes.
7. Turn the key back to LOCK and remove from ignition to exit programming mode.
Transponder Programming has to be done by a licensed automotive locksmith. You can find a local locksmith using this website: autolocksmithfinder.com
Works on:
Acura RDX (2008-2012), Acura MDX (2007-2013).
Programming Procedure #510 & 99
Keyless Entry Remote Programming:
IMPORTANT: Entering the programming mode cancels all learned remote codes, so no previously programmed remotes will work. You must program all remotes, including existing ones now. Separate your ignition key from remotes on keychain.
- Start with your key in your right hand and any remote in your left hand. Keep all additional remotes easily accessible to your left hand. Insert the key into the ignition.
- Perform these steps within 5 seconds.
- Turn the ignition to the ON position (where the instrument panel lights are turned on without starting the engine.)
- Press the UNLOCK button on the remote and release.
- Turn the ignition back to LOCK (the position where the key is inserted) and leave the key in the ignition.
- Turn the ignition to the ON position (where the instrument panel lights are turned on without starting the engine.)
- Press the UNLOCK button on the remote and release.
- Turn the ignition back to LOCK (the position where the key is inserted) and leave the key in the ignition.
- Turn the ignition to the ON position (where the instrument panel lights are turned on without starting the engine.)
- Press the UNLOCK button on the remote and release.
- Turn the ignition back to LOCK (the position where the key is inserted) and leave the key in the ignition.
- Within 5 seconds turn the ignition to ON.
- Press the UNLOCK button on the same remote and release. The power door locks will cycle to confirm the system is in programming mode.
- Within 10 seconds press the UNLOCK button on the same remote again and release. The door locks will cycle to confirm that the system accepted this remote.
- Repeat step 5 for second or third remotes.
- Turn the key back to LOCK and remove from ignition to exit programming mode.
Transponder Key Programming:
Use the websites below or your local yellow pages to locate a local automotive locksmith.
www.autolocksmithfinder.com
An automotive locksmith will cut the key and program your vehicle to start with new keys by hooking up an expensive scan tool to your vehicle, making the vehicle learn the new transponder chip.
Compatibility
